Máy in mã vạch công nghiệp Xprinter XP-G480B

Độ phân giải

203 DPI

300 DPI

Phương pháp in

Thermal Transfer / Direct Thermal

Tốc độ in

200 mm (8″) / s Max.

152 mm (6″) / s Max.

Khổ giấy

108 mm (4.25”)

106mm (4.17”)

Chiều dài nhãn

2286 mm (90”)

889 mm (35”)

Media

Kiểu nhãn in

Continuous, gap, black mark, fan-fold and punched hole

Kích thước đầu in

20 ~ 120 mm (0.78″ ~ 4.7″ )

Media thickness

0.06 ~ 0.254 mm (2.36 ~ 10 mil)

Label length

10 ~2286 mm(0.39″ ~ 90″ )

10 ~ 889 mm(0.39″ ~ 35″ )

Media core diameter

203 mm (8”)

Ribbon

127 mm (5“) OD (outside wound)

Ribbon capacity

600 M

Ribbon width

110 mm

Performance Features

Processor

32-bit CPU

Memory

128MB Flash Memory / 128MB SDRAM / Flash memory can be expanded Max.4Gb

Interface

USB / Serial / Lan,  Optional: Parallel/WIFI/TF card/Bluetooth

Sensors

① Gap sensor     ② Cover opening sensor     ③ Black mark sensor     ④ Ribbon sensor

Fonts/Graphics/Symbologies

Internal fonts

8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.

1D bar code

Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11

2D bar code

PDF-417, Maxicode, DataMatrix, QR code, Aztec

Rotation

0°、90°、180°、270°

Emulaion

TSPL、EPL、ZPL、DPL

Physical Features

Dimension

504 mm (D) × 257 mm (W) × 297 mm (H)

Weight

10.22 kg

Power supply

Input

AC 100-240V, 50-60Hz

Output

DC 24V / 2.5A, 60W

Options

Factory options

① RS-232C(2400-115200 bps) communication interface;
② Ethernet server(10/100 Mbps)；
③ WiFi module
④ Bluetooth module
⑤ Paralled
⑥ Peel⑦ Cutter

Dealer options

① External paper roll holder and 1 “paper roll
② Extension board for external paper roll holder

Environmental Conditions

Operation environment

5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% no condensing

Storage environment

-40 ~ 60°C（-40~140°F），Humidity: 10 ~ 90% no condensing
