Máy in đơn hàng A6 (100×150) Tiktok Shop, J&T, Shopee, Tiki, Logo tự dán, minicode Xprinter XP-D463B (USB + Bluetooth)

Resolution

203 DPI

Printing method

Direct Thermal

Max.print speed

152mm (6 “) / s Max.

Max.print width

108mm (4.25″)

Max.print length

1778 mm (70″)

Media

Media type

Continuous, gap, black mark, fan-fold and punched hole

Media width

26 mm ~ 116 mm

Media thickness

0.06 mm ~0.20 mm

Label length

10 ~ 1778 mm

Gap height

≤2mm

Black mark height

≤2mm

Performance Features

Processor

32-bit CPU

Memory

8MB Flash Memory / 8MB SDRAM

Interface

USB + Bluetooth

Sensors

• Gap sensor
• Cover opening sensor
• Black mark sensor
• Paper exit sensor

Fonts/Graphics/Symbologies

Internal fonts

8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software

1D barcode

Code 39, Code 93, Code 128UCC, Code 128 ，subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST

2D barcode

PDF-417, Maxicode, DataMatrix, QR code

Rotation

0°  /  90°  /  180°  /  270°

Emulaion

TSPL  /  EPL  /  ZPL  /  DPL

Physical Features

Dimension

185 mm(W)× 85 mm(H)× 85 mm(D)

Weight

722 g

Print head life

30 km

Driver

Windows/Linux/ Mac

SDK

Windows/Android /iOS

Input

AC 100-240V, 50-60Hz

Output

DC 24V, 2.5A

Factory Options

①WIFI
②Bluetooth
③Cloud WIFI

Dealer Options

External paper roll holder

Operation

5 ~ 40°C(41~104°F), Humidity: 25 ~ 85% non-condensing

Storage environment

-40 ~ 60°C(-40~140°F), Humidity:10 ~ 90% non-condensing
